The National Physical Laboratory and Queensgate share an unrelenting passion for better precision at the cutting edge of measurement science Queensgate XY stage in AFM at National Physical Laboratories Queensgate – a brand of Prior Scientific Instruments – offers their customers maximum precision and accuracy along with high-speed solutions for the nanopositioning challenges they face. […]
News
Prior Scientific Introduces the NanoScan NPC-D-6000 Series Multi Channel Controllers
Prior Scientific are pleased to announce the release of our Queensgate NanoScan NPC-D-6000 Series Multi-Channel Closed Loop Controllers. Both the single and multi-channel digital nanopositioning controllers are designed to operate in a closed loop feedback mode with stages or actuators incorporating capacitive position sensors. The controllers deliver: Low noise Low drift High power Best resolution […]
Queensgate Instruments has been acquired by Prior Scientific Instruments Ltd
Prior Scientific Instruments are global leaders in delivering high precision motorized stages, microscope automation products and specialty opto-mechanical automation systems. Queensgate instruments designs and produces leading performance nano positioning and measurement systems used in a wide range of applications from atomic force microscopy, hard disc testing, lithography and metrology. Both companies have significant experience delivering customised solutions […]
Smaller Worlds – John Andrew Clarke of Queensgate Instruments looks at the shrinking world of nanopositioning
In most fields of engineering, working to micrometre accuracy is considered to be the standard, with typical high-quality bearings having tolerances within hundreds or even tens of microns. But pioneers working in nanopositioning are now operating at tens of picometres – a million times smaller. For comparison, an atom is around one to five-hundred picometres […]
The incredible world of nano positioning
Queensgate Instruments specialize in creating nano positioning and sensing solutions for high-technology industries, with variants suitable for precision measurement in UHV, radiation environments and cryogenic temperatures. Positioning control With data and processing demands increasing year on year, there is a constant drive to make technology ever smaller. This presents new challenges for manufacture and inspection […]
Meeting the demands of positioning and sensing in UVAC environments
UVAC versions of the Queensgate Series NanoSensors and our DPT-D and DPT-E ranges of Digital Piezo Actuators are widely used in Synchrotrons and Beamline applications. NX/NZ NanoSensors The NX/NZ non-contact position measuring systems are based on the principle of capacitance micrometry with superior resolution and stability performance. Two sensor plates (the target sensor and probe […]
Subnanometre positioning in a vacuum – the NC Nanosensor capacitive sensor series
The NC NanosensorTM capacitive sensor series, has been specially developed to meet the requirements of partial accelerators. The NCG-1-AL-UHV Capacitive Sensors are the longest range sensors in the Queensgate range. Designed for high resolution positioning in harsh environments. The NanoSensors are non-heating and maintain their zero position when powered down. Originally developed for magnet positioning inside vacuum, it offers […]
Astronomy and space science nanopositioning solutions
Space and space challenges Over the decades, Queensgate Instruments has undertaken various one-off space-borne projects as subcontractor and in collaboration with companies working for NASA and ESA. These included precision capacitance micrometers used in the “force moment sensor”, part of the robot-arm mechanisms used on the International Space Station and the Space Shuttle. The capacitive sensing systems […]
The National Physical Laboratory (NPL) – Testing nanopositioning devices for Queensgate
The National Physical Laboratory (NPL) has a long standing collaboration with Queensgate Instruments in the area of provision of metrology for nanopositioning. NPL and Queensgate recently completed an Innovate UK project in which NPL developed optical interferometry to enable Queensgate to verify the performance of the next generation of its nanopositioning stages. Queensgate’s nanopositioning devices […]
